SMP-MB Meiyo Electric Pressure Transmitter

SMP-MB Meiyo Electric Pressure Transmitter

Be the first to review this product

Availability: In stock

$220.00
OR

Quick Overview

SMP-MB Meiyo Electric Pressure Transmitter

SMP-MB Meiyo Electric Pressure Transmitter

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details

SMP-MB Meiyo Electric Pressure Transmitter (never used. 98% new)

Techanical data and Ordering

Power supply

DC 24V(-25% ~ +30%)

Power supply ripple

500mv p-p less

Output signal

DC 4~20mA

Load resistance

550Ω at 24V DC

Accuracy

500g for 1ms to IEC 60068-2-27

Enclosure

IP 54

Cable gland

JIS F 8801 15c

Color of case

Maker’s standard

Material

Connection port : SUS, case : ALDC

Weight

0.53Kg

Operating temperature

-20°C ~ 70°C, compensation temperature 5 ~ 55°C

Vibration resistance

3~30Hz amplitude 1.13mm and 30~300Hz acceleration 4G

according to IEC 60068-2-6. The requirements of the ship

classification societies are up to 100Hz, acceleration 4G

Extended specifications by prior arrangement.

Noise immunity

Complies with the standard for industrial apparatus EN

61000-6-2. The standard contains tests for the following : HF

fields, main Transmitted HF, voltage transients, electrostatic

immunity, supply

Voltage variations, low-frequency radiation and transient

protection In accordance with Germanish Lloyd.

Noise emission

Complies with standard EN 61000-6-3
