Oil content Contamination Monitor, OCM-15 jiujiang unique oil content meter

Oil content Contamination Monitor, OCM-15 jiujiang unique oil content meter

Be the first to review this product

Availability: In stock

$1,200.00
OR

Quick Overview

Oil content Contamination Monitor, OCM-15 jiujiang unique oil content meter

Oil content Contamination Monitor, OCM-15 jiujiang unique oil content meter

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details

OCM-15 15ppm Bilge Water Alarm Device is a new generation of online monitoring instrument for detecting trace oil concentration in sewage. It is suitable for continuous monitoring of ship and ship bilge oil sewage discharge. . It is generally used with 15ppm bilge oil sewage separator.

The OCM-15 type 15ppm bilge water alarm device has passed the China Classification Society (CCS) type approval, and its performance indicators meet the requirements of the International Maritime Organization Marine Environmental Protection Committee Resolution MEPC.107 (49).

Features:

(1) Adopt the priority of multi-band infrared measurement principle and micro-processing technology, fast response time and high measurement accuracy;

(2) The overall anti-electromagnetic interference design is adopted to overcome the impact of the use environment on the instrument and improve the system stability and reliability of the instrument;

(3) Real-time display of oil concentration and system working status;

(4) Real-time recording of various alarm status data and automatic storage, query and print historical data at any time;

(5) The measurement room is easy to maintain and clean, and the operation is simple;

(6) The instrument has a working state monitoring function, which can automatically control the discharge of excess sewage when the instrument is faulty, repaired or replaced.

OCM-15 main technical parameters

model

OCM-15

range

0-30mg / l can be expanded to 50mg / l

Precision

Better than 5mg / l

Linear

Above 2%

display

LCD display

powered by

220VAC/110VAC ±10% 50Hz/60Hz 5%

power

10VA

Alarm point

1-15ppm

Alarm point factory setting

15ppm

Alarm Output

2 relay outputs

Alarm relay output contact rating

5A, 250VAC, non-inductive

Alarm indication

Red LED

output signal

4-20mA, load resistance ‹500 ohms

Sample water pressure

0.01-6bar

Ambient temperature

0 to +55 degrees Celsius

Sample water temperature

+1 to +80 degrees Celsius

Size (overall)

360mmW × 240mmH × 105mD

Protection class

IP45

weight

7kg

Pipe connection

R 1/4 "internal thread

Standards compliant

Resolution IMO.Res.MEPC.107 (49)
