JOHNSON CONTROL TYCO SEAPLUS WATER MIST SYSTEM FIRE ALARM CONTROL PANEL MODEL : JB-QB-4508

JOHNSON CONTROL TYCO SEAPLUS WATER MIST SYSTEM FIRE ALARM CONTROL PANEL MODEL : JB-QB-4508

Be the first to review this product

Availability: In stock

$1,200.00
OR

Quick Overview

Main supply power AC 220V(min. AC 187V, +10% ~ -15%), 50/60 Hz
Stand-by supply power DC 24V, 7AH(default), Increasable : OPTIONAL !
Power consumption Monitoring Status : ≤2.4W, Alarm Status : ≤10W

PCB(INTERFACE BOARD UNIT) FOR JB-QB-4508

JOHNSON CONTROL TYCO SEAPLUS WATER MIST SYSTEM FIRE ALARM CONTROL PANEL MODEL : JB-QB-4508

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Details



(1) 4×20 character digital LCD(Liquid Crystal Display), which can show the all information of the system operating clearly.
(2) Main menu system for easy operating.
(3) Isolation function of group(loop) & individuals(detector and remote control module).
(4) Manual & auto operation mode by user.
(5) 4 detecting loop of 2-wire(P+, L) bus system for detector and remote control module.
(6) Watch dog system for safe operating.
(7) Addressable detector & remote control module and programming function of address text, which can define the device type & location in detail by computer.



Main supply power AC 220V(min. AC 187V, +10% ~ -15%), 50/60 Hz
Stand-by supply power DC 24V, 7AH(default), Increasable : OPTIONAL !
Power consumption Monitoring Status : ≤2.4W, Alarm Status : ≤10W
※ Current : 400 mA (normal state), 500 mA (alarm state)
Basic Monitoring Capacity 508 fire detectors / 60 remote control modules / 1~4 Loops
Polling cycle ≤ 10 seconds(Single-point check continuously when abnormal)
Signal transfer distance ≤ 1,500 Meters
Wiring Method Detector and module : 2-wire (P : positive pole, L : negative pole)
Line conductor RVS - 2×1.5mm2
, Double colors, couple hunk,
multi-prong plastic soft line
Operation temperature 0℃ ~ 55℃
Relative humidity ≤ 95%
Dimension
(W×H×T)
Fire alarm system Main panel & Repeater : 290×180× 78 mm
Interface unit box : 514×370×150 mm
Installation Wall-mounted or Flushing-mounted
Weight Fire alarm system Main panel & Repeater : Approx. 1.7 kg
Interface unit box : Approx. 17 kg
