Pressure conversion ratio: 30: 1
Max. flow displacement(L/min): 6
Inlet pressure(MPa): 0.3-0.6
Air consumption(L/min): 180-2000
Cylinder diameter(mm): Ф125
Dimensions(mm)width×height×high: 480×480×800
Weight(kg): 32
Note: The no-load displacement is the displacement pressure of the coating under
High pressure airless coating equipment Scope：Can be spray Encaustic tile、Furniture、Steel structure、Ships、Constructs the inside and outside wall latex paint、Tannery spray coating glue water、Each kind of coating and Paint Pressured air as the power,steady and reliable,malfunction ratio is extremely low. Pressure pulsation is small;the coating layer is even,the coating quality is better. The route is long,the exhaust is big,the frequency of switching direction is low,hard to be damaged by friction,the life of the machine and the maintenance cycle extends. Use new type silencing device. It is a type of small car,the structure is close,the movement is convenient.
