Double Deck Navigation port red Light 112.5° 3nm CXH2-101P

2*60W 112.5° 3nm

luminous intensity 60cd

lamp holder p28s

protection IP56

Cable outside diameterø 10mm.

• The scope of application:
This light fits for the ships with the length 50m or above 50m as
lamp signal communication when night navigation.
• Products feature:
I . This lamp can be installed conveniently and its bulb can
be replaced easily.lt can replace the bulbs after open the up
cover.
2.There are automatic leak holes on the bottom of light.
3. The shell adopts high-strength engineering plastic with
watertight, good corrosion resistance, impact resistance and
other characteristics.
4. The lampshade adopts Poly carbonate material which
has the feature of ultraviolet radiation resistance and non-
discoloring.
5. The signal lights adopt the signal light' s bulb which
conform to the ship norm and the average life not less than 700
hours.
6.The signal lights can work normally under the temperature
-300 +500 .
7 .Cable outside diameterø 10mm.

• Adopt standard and products certification:
l. Conform to INTERNATIONAL REGULATIONS FOR
PREVENTING COLLISIONS AT SEA 1972.
2. Conform to international standard of IEC60598-l -2008 .
3. Conform to performance standard of requirement about
IMO Res.MSC.253(83).
4. Conform to national standard of GB/T3028-2012.
5. Conform to RULES FOR CLASSIFICATION OF SEA-GOING
STEEL SHIPS.
6. Approved by China Classification Society (CCS) and Type
Approval of China Fishery Inspection Bureau. (ZY)
7. Passed the European Union (CE) certification.
